Printhead: |
Mirco piezo dot-on-demand printhead-2
4 color: C,M,Y,K
Height adjustable range:2-5 mm |
Resolution: |
1440dpi(Max) |
Printing width : |
1.8m(Max) |
Printing speed: |
Draft Model:540*720 dpi 50sq.m/h
Production model: 720*720 dpi 26 sq.m/h
High quality model: 720*1440 dpi 19sq.m/h |
Heating system: |
Front,Middle and back, three section heating system,PID temperature controller
Adjustable range: Room temperature -80 degree |
Drying system: |
Outer Fans |
Medias: |
Max width: 1.8m
Media handling system: Auto media feeding,,Manual media releasing
Built-in variable adsorption
Media Type: Adhesive Vinyl,PVC,Mesh,Textile,Banner,Eco-solvent ink paper etc |
Inks: |
Eco-solvent pigment inks
Eco-solvent Dye Sublimation inks
Eco-solvent Dye inks
Water based inks
Ink cartridge:350ml--16 pices
|
RIP: |
iPrint 3.0 professional Bi-Language RIP(Chinese& English)
From: Tiff,Jepg etc
PostScrip file interpreter(0ptional) |
Driver: |
Professional Bi-language software(Chinese & English) |
Interface: |
USB 2.0 RS 232 |
Working system: |
Windows XP |
Input Power : |
AC 220-240V 50/60HZ |
Working Environment: |
1000W(Max. power) 300W(Normal working power emperature: 20-25 Degree
Humidity: 40-70%, non condensation |
Physical Specifications: |
Printer dimension:(W*L*H) 2.84 *.9*1.25m(with stand)
Packing Dimension:(L*W*H) 3.0*0.93*0.73m(with stand)
Net Weight: 160KG(with stand)
Gross Weight: 240KG(with stand) |
